UV devices

We deliver UV DISINFECTION units from stainless steel and filter hosuings.

Germicidal devices UVETTA Germicidal lamps are UV disinfection devices suitable for home or office use. Easy to use, 100% efficient. Find out more 400 TC Series In this Series of UV systems uses powerful lamps that will allow, at the same treated flow rate, the use of less lamps and so on easier maintenance Find out more AM series SITA series is the powerful low pressure amalgam lamp, that permits a very good disinfection also with low UV Transmittance values Find out more Domestic series The UV disinfection systems of the DOMESTIC SERIES are the smallest equipments manufactured by us, both for dimensions, and for capacity of water treated. Find out more HDPE Series UV series realized in high density polyethylene UV chambers, that guarantee a long life with agressive water. Find out more IT Series SITA IT VALIDATED series is biodosimetrically tested according Austrian norm and full fit the EPA requirement. Find out more Rack LCD series Disinfection units of Rack LCD Series are composed by one UV chamber with more lamps. Find out more SBT series SBT Series designed specifically for low UVT trasmittance values. Find out more SMP Series SMP unit has the ability to break chemical bonds, and have a good reduction of unwanted chemicals in water. Find out more SMP3 Series SMP3 je pravděpodobně ta nejmenší střednětlaková jednotka na trhu, vynikající volba pro bazény s nedostatkem prostoru a slabou recirkulací. Find out more Special units The technical office of our producer is able to size UV devices to suit the client's specific request. Find out more

WHAT ARE UV-C RAYS ?

The small part of electro-magnetic spectrum having wave lengths included between 100 and 400 nm (thousandths of micron) is defined as space of the ultra-violet irradiation. The UV-C are part of the subspace characterized by the wave lengths included between 100 and 280 nm. Electro-magnetic waves with different wave length and width induce interactions with the matter of different nature, the UV-C irradiation with l= 254nm is particularly interesting thanks to its marked germicidal power.

HOW THEY ARE PRODUCED ?

HOW THEY ARE PRODUCED ?

In nature the UV-C rays are part of the secondary cosmic irradiation which, interacting with the high strata of the terrestrial atmosphere, generates ozone and with a lower energy, it reaches ground as tanning UV(A+B) irradiation. Artificially UV-C rays are produced with the help of special fluorescent lamps containing mercury fumes, these lamps are made of a very pure quartz (>99.99% SiO2) transparent to the UV-C light which they emit in an almost monochromatic form (>95% of Ć = 254nm).

HOW MUCH DO THEY WORK ?

HOW MUCH DO THEY WORK ?

For being effective in the disinfection, an electro-magnetic wave, besides being of a certain kind (L = 254nm) it must possess also a minimum value of intensity to be able to ensure a minimum dose to water. A UV sterilizer, if correctly sized, is able to give water a dose sufficient for reducing almost all the commonest micro-organisms present in water. Normally a UV disinfection system must have a UV dose higher than 300 J/m2.

WHY DO THEY WORKS ?

WHY DO THEY WORKS ?

The high germicidal power of this wave length must be sought in DNA and in the link of its fundamental components (nucleotids). DNA is a macromolecule present in all living organisms in which all information necessary for life and reproduction reside. The alteration, induced by the UV-C irradiation, of some chemical links present among nucleotids is able to change the information contained and conveyed by DNA, these alterations prevent its normal activity and this irreversibly leads to the cellular death.
